Detail Information
1. It used for milling the holes of hardware.
2. Use of imported special aluminum alloy original cutter, and the original models for insulation and high precision machining of aluminum alloy doors and windows, high efficiency to improve the characteristics, size precision milling and processing of surface smoothness to meet the domestic advanced level.
3. Use of imported special aluminum alloy original cutter, and the original models for insulation and high precision machining of aluminum alloy doors and windows, high efficiency to improve the characteristics, size precision milling and processing of surface smoothness to meet the domestic advanced level.
4. Copying can be processed.
Technical Parameter:
Cutting surface roughness Ra12.5μm
Speed 2800rpm
Working pressure 0.5-0 .8 M pa
Cutter diamete Φ5mm Φ8mm
Diameter drill Φ12mm
Profiling range 290 × 90mm
Size (length width × high ×) 870mm × 700mm × 1500mm
Weight: 270Kg
