Product Name:Window machine--Corner Connector Automatic Cutting Saw for Alu-door-window LJZ-500X600
Sort:Aluminum Ingot
Company:Jinan Xinwuyue Machinery Factory
Location: China
Contact Person:Macy Wang
Post Time:2009/7/24
Free Member
Jinan Xinwuyue Machinery Factory
Tel:86-531-88268516
Fax:+86-531-88268506
Add:No.182-30,North Industry Road,Jinan city,china
Post Code::250101
E-mail:xwywang@hotmail.com
Detail Information
1. It is the special equipment for cutting the corner connector of the frames and fans for the ALU-door-window and curtain wall.
2. Adopt the imported INTEL special cutting saw for the aluminum alloy, high processing precision.
3. The feeding structure adopts the linear guiding rail moving pair, small motion-resistance force and high precision.
4. The feeding machine adopts imported linear bearing pair, automatic feeding, stability and high efficiency.
5. Adopt the imported Programmable Control System (PLC).
Technical parameter
The cutting width Max:140mm
The cutting height Max:140mm
Power supple 380V 50HZ (three-phase four-wire system)
Blade size Φ500×Φ30×4.4×Z120mm
Motor rotary speed 2800rpm
Cutter feeding speed 0-3m/min
Auto feeding length 3-600mm
Working pressure 0.5-0.8Mpa
Air consumption 60/min
Contour dimension (length width height) 1500mm×1100mm×1600mm
Wight: 850kg
