The production line of food container of aluminium Modle:CTJF-40T The productivity is 40-70 per minute ,that is to say, this production line can produce 40-70 products per minute.(it depends on the productions complexity and size.) The fastest speed is 70 products per minute.Every mould has one cavity.If the product is small, a mould has two or more cavities. This prodution line is composed of the followings(note1), 1. an auto-lubricated feeder(note2) 2. an eletronically controlled panel 3. a length controller 4. a 40T pneumatic punch 5. a set mould of food container which is vertical curl or full curl. 6. a automatic conveyor(with a carbore which can be filled the resting foil) 7. a collector of finished product 8. a machine which assist to change die 9. a machine which assist to change foil Note: 1.This production line is electrification integration,and centralized control.It is totally controlled automatically.Worker just collect the finished products. 2.The width of foil feed system is 520mm.(basic model) 3.The lenth of feeding foil is controlled by computer. You can regulate the length form 30mm to 999mm. 4.As we can manufacture the machine according to the products’s size as they required, the outer-appearance of the machine is a little bit different. The procedure of production line: raw material:aluminium foil-->auto-lubricated feeder-->pinch head controller-->40-T precise presser--> mould-->collect product by hand (or auto-collector)-->packing Instrution of mould: It is said that perfect products should be produced by the good mould which is the goal we endeavor to. We abandon outdated mechanical operation of the mould and adopt the star uprebounded system which is flexible. The advantages of the mould are long shelf life, stable quality, high precision, reasonable design. With such advantages, the mould could realize the process of cutting, forming, plugging and rolling of aluminum foil wares at one time, also, it is suitable for the production of aluminum foil wares with smooth surface, multi cavities and various edges (G style, L style, IVC style or folding style). The mould is excellent in quality and reasonable in price.The working cycle period is short. According to customers needs, the mould can be seted up to ordinary punch, pneumatic punch,or the press with four pillars.
